cubes / bacon

Supreme TRI01

Machine to cut cubes of fresh meat for pre-salting before mincing from a whole raw material put in a large volume cutting chamber.

The content of the chamber is pushed through a tool with two alternative cuttings and a rotating blade. This machine has a 3D cutting system.

The TRI01 is integrated at the end of the cutting table: The boners can store the boneless pieces on the machine platform. The integrated weighing system allows you to know the mass of meat stored before cubing.

The TRI01 Supreme Hydraulic Slicer is an industrial tool for pork butchers and salting workers, allowing to cut 90kg of meat / min into a 40mm section cubes (more than 5 tonnes / hour).

Loading chamber capacity
: 15 kg of fresh meat
Height: 120 mm
Width: 180 mm
Length: 700 mm

Power: electrical control, hydraulic, pneumatic and electrical power.
Materials: stainless steel and polymers

The rules dictated by EHEDG for the manufacture of machines dedicated to the food industry allow us an optimum design in order to meet your sanitary requirements

This material is in conformity with the following directives and bills:
Food contact: EC1935/2004
Good manufacturing practice: EC2023/2006
Machines: EC2006/42
CEM: EC 2004/108

advantages

Supreme TRI01

The TRI01 Supreme hydraulic slicer combines hydraulic power and reliability with electronic control.


Ease of cleaning thanks to a design taking into account agri-food constraints.


Ergonomics of the loading station optimizing the gestures and movements of the operators.


Integrated weighing to manage batches of meat and recipes.


A touch screen makes the communication easier between the operator and the machine. The screen includes a self-diagnostic system displaying a picture of the faulty component for example.
